When I started using Unix back before some LEB readers were born, configuring swap was crucial.

For those who might not know, swap is the use of a disk drive for RAM substitution.  If you have a VPS with 1024MB of RAM and you have no swap, when you try allocate the 1025th MB of RAM, it’s going to fail.  If you have some swap space, then the kernel will look for some RAM that isn’t in use.  You may have some background processes (or even running processes) that have allocated RAM but aren’t using it at the moment or haven’t touched it in a while.  The kernel will take those RAM pages and write their contents to disk, freeing the RAM.  Then later if the process needs to access those pages, they’re read from disk and brought back into RAM.

I’m simplifying slightly, because there are actually a couple different flavors.  “Paging” is the modern method of moving individual pages of RAM to disk, while “swapping” is an older technology that moved entire processes.  But it’s the same idea.

All of this happens transparently, nut not without cost.  Disk is at least an order of magnitude slower than RAM, so using swap is much slower than RAM.  Additionally, it can introduce janky latencies in applications because at random times a memory fetch has to go to slower disk.

Swap was Dead

Back when a big server had 256MB of RAM, swap was crucial.  Configuring it, sizing it, and monitoring it was part of sysadmin life.  We all had monitors that alerted when swapping was happening.

But once RAM got into the multi-gigabyte range, swap became a lot less important.  When a server is small, the core parts of the OS – kernel, background processes, etc. – take up a large part of the overall RAM.  Let’s say they take 125MB.  That’s half of RAM if your server has 256MB.  But when your server has 8GB of RAM, it’s less than 2%.

In recent years, a lot of people just haven’t bothered.  I’ve provisioned VMs that don’t have minimal swap and it rarely seems to be used.

But that was before the RAM price apocalypse.

Swap is Back

Now that memory prices are spiking, VPS plans may increasingly ship with stingier RAM, or the price of the plans may go up.  This means we all may need to learn to live with swap again.

The good news is that instead of putting swap on old spinning hard drives, you’re putting it on NVMe, which is much faster.  But it’s still not nearly as fast as RAM.

And the swapping technology itself is better.  Modern Linux kernels use zswap, which compresses pages before writing them to disk.  Sure, you need to uncompress them to use them, but most systems have extra CPU power to burn.

Long story short…you probably are going to need to shake the dust off your swap management skills.

Swap File vs Swap Partition

Historically Linux used swap partitions, but today swap files are usually better.  Swap partitions have slightly less overhead and are always available early during boot, but they’re harder to resize, require the forethought to partition your disk for them, and you really shouldn’t need them at any point in the boot process.

Swapfiles are just a file, like /swapfile.   They’re easy to create or resize and don’t require pre-planning with partitions.

How to Create Swap (Step-by-Step)

Here is a typical example creating a 2 GB swap file.  All these commands assume you’re root.

First, create the file:

fallocate -l 2G /swapfile

Or:

dd if=/dev/zero of=/swapfile bs=1M count=2048

and then:

chmod 600 /swapfile

Next, format it as swap:

mkswap /swapfile

Finally, enable it:

swapon /swapfile

You can use free(1) to check

# free -h
               total        used        free      shared  buff/cache   available
Mem:           3.8Gi       559Mi       3.2Gi       111Mi       512Mi       3.3Gi
Swap:          1.0Gi       706Mi       315Mi

Be sure to add an entry in /etc/fstabto enable at boot:

/swapfile none swap sw 0 0

Swappiness

In Linux, the swappiness parameter controls how aggressively the kernel moves pages from RAM to swap.  Values range from 0 to 100.

Most servers benefit from lowering swappiness.

You can check the current value by examining /proc:

cat /proc/sys/vm/swappiness

Default is usually 60.

To change it, use sysctl:

sysctl vm.swappiness=10

And to make this change permanent, edit /etc/sysctl.conf:

vm.swappiness = 10

And then apply it:

sysctl -p

Recommended Swap Sizes

This is really a black art and it all depends on what you’re doing.  Here’s some good starting points:

Not sure?  2GB.
